Robust Brakes is one of the top manufacturers of brake linings for heavy duty commercial trucks. We expertise in designing and manufacturing superior quality non-asbestos brake linings that suits the customer needs.
Our Brake lining is excellent in stability and have undergone extensive and rigid testing in laboratories. They have stable coefficient of friction over a wide range of temperature and speed.
We offer 4 different qualities of brake lining recommended for different applications as required.
RB Economy Brake Lining (Black Colour)
It's a solid block with secure stopping ability. It is especially well suited for applications involving long-haul, intercity, and general freight. It is kind to the mating surface and exhibits good heat stability. It works perfectly with automatic slack adjusters because of its low swell feature.
| DYNAMOMETER TEST PARAMETERS | |
| Material | RB20KS |
| Brake Size | 16.5 X 7 |
| Brake Type | Arvin Meritor |
| GAWR(lbs) | 20,000 |
| Rolling Radius (inch) | 19.6 |
| Air Chamber | Type 30 Long Stroke |
| Slack Adjuster (inch) | 5.5 |
RB Standard Brake Lining (Blue Color)
| DYNAMOMETER TEST PARAMETERS | |
| Material | RB20KP |
| Brake Size | 16.5 X 7 |
| Brake Type | Arvin Meritor |
| GAWR(lbs) | 20,000 |
| Rolling Radius (inch) | 19.6 |
| Air Chamber | Type 30 Long Stroke |
| Slack Adjuster (inch) | 5.5 |
RB Premium Brake Lining (Red Color)
| DYNAMOMETER TEST PARAMETERS | |
| Material | RB23KS |
| Brake Size | 16.5 X 7 |
| Brake Type | Arvin Meritor |
| GAWR(lbs) | 23,000 |
| Rolling Radius (inch) | 19.6 |
| Air Chamber | Type 30 Long Stroke |
| Slack Adjuster (inch) | 5.5 |
RB Supreme Brake Lining (Green Color)
It is a non-Asbestos grade material. Its flexural strength and lining life are outstanding. Its retardation, recovery, and fading are all good. It is soft on the drum and features judder-free, seamless braking. Applications with medium to high duty can use it. Application: Passenger buses, trucks, trailers, and heavy-duty tractors.
| DYNAMOMETER TEST PARAMETERS | |
| Material | RB20KP |
| Brake Size | 16.5 X 7 |
| Brake Type | Arvin Meritor |
| GAWR(lbs) | 23,000 |
| Rolling Radius (inch) | 19.6 |
| Air Chamber | Type 30 Long Stroke |
| Slack Adjuster (inch) | 5.5 |
